Recoil DII1600.1 3200W Ultra-Compact Class-D Monoblock Car Amplifier

Description DII SERIES AMPLIFIERS Don’t let Recoil DII series amp’s modern styling and small size fool you though, Utilizing the latest Class-D technologies, the ultra-compact DII series amplifiers are engineered to deliver loads of audio output power, with incredible efficiency. For your convenience, the DII amps’ controls can be found on top of the amplifier, beneath a protective cover. • Recoil proprietary Class-D technology • 4/2 Ohm muti-impedance constant power • 4 Ohm bridged capable • Turn-on mode selection (REM, VOX, DC) • Top mounted control panel • 2/4 channel input switch • RCA pass-through outputs • Clip detection and indicator LEDs   SPECIFICATIONS 4-Way Protection Circuit: Thermal, Voltage, Speaker, DC Power @ 1 Ohm (14.4V): N/A Power @ 2 Ohm (14.4V): 1600W × 1 Power @ 4 Ohm (14.4V): 820W × 1 Power (Bridged) @ 4 Ohm (14.4V): N/A Power (Bridged) @ 2 Ohm (14.4V): N/A Operating Voltage: 9V–16V Idling Current (Power On): 180mA Frequency Response: 10Hz–20kHz Signal-to-Noise Ratio (SNR): 86dB THD N (@1W): < 0.06% Input Sensitivity (Low Level): N/A Input Sensitivity (High Level): 230mV–12V Bass Boost: 0–12dB Subsonic Filter: 10Hz–20Hz Crossover LPF: 40Hz–280Hz Crossover HPF: 10Hz–80Hz Bass Remote: Yes Clip Indication: 1% Fuse Rating: 95A Dimensions: Inches: 9.8″ × 5.4″ × 2.1″ Metric: 250mm × 136.5mm × 53mm
