Description Technical Specification Speaker Level Input: 1 (2 channels) Maximum Speaker Level Input: 40 Vrms / 400 W (20k ohm setting) Input Impedance (selectable): 20 ohm, 60 ohm, 20k ohm outputs Preamp Outputs: 2 (2 channels main, 2 channels bass) Maximum Output Level: 9.5Vrms/13V peak Output Gain: /- 12 dB Output Impedance: 150 ohm performance Total Harmonic Distortion: 0.01% Signal to Noise: >110 dB Frequency Response: 20 Hz ? 50 kHz ?1 dB control Remote In / GTO? Signal Sense / Audio Sense 12VDC Remote Out (always active when unit is on) general Current Draw: 200 mA Recommended Fuse Rating: 1 A weights & dimensions Dimensions: 6.9 inches L x 3 inches D x 1 inch H (including speaker connectors) Weight: 0.75 lbs. (0.34 kg)
