Description FULL DA HD Pure digital signal transfer with a resolution up to 24 bit / 96 kHz DIGITAL INPUTS AND OUTPUTS Innovation is at the heart of the state-of-the-art digital decoding section. The S/PDIF optical input allows direct connection to digital sources with the ability to re-launch the digital signal to other Thesis amplifiers through the AD Link (Audison DigitalLink) system. Each amplifier features 192 kHz/24 bit PCM D/A conversion through a very high quality converter. BIAS CONTROL Provides the selection of four possible presets: Energy Saving, Hi-Current, Hi-AB Class and full A Class operation. REMOVABLE CROSSOVER Inherited from the HV venti and making the most of TH extreme versatility, the complete crossover circuit of the TH amplifier is removable; a high-end sound quality solution. DUAL MONO CONSTRUCTION Four Synchro-PWM power supplies allow for a very fast transient current response and to create a Dual Mono configuration. Power Output Load Imp. Mono Dual Power – Hi-Current 4 Ohm 850 W x 1 2 Ohm 1500 W x 1 1 Ohm 2300 W x 1 Dual Power – A Class 4 Ohm 200 W x 1 Amp Chain 4 Ohm (2 Amp) 3000 W x 1 2 Ohm (2 Amp) 4500 W x 1
